| Specification | Date: 12/22/2024 |
| Inventory #: | C5358TS |
| Machine Type: | CNC Machining Centers - Pod and Rail |
| Manufacturer: | Biesse |
| Model: | Rover B 4.35 |
| Year: | 2004 |
| Region: | Central Canada |
| Voltage: |
600/3/60
Can be transformed to required voltage for a nominal fee. Single phase available thru a phase converter. |
| Condition: | Good |
| Machine Capacities: | -Working field, X-axis: 3200mm (125.9") -Working field, Y-axis: 1315mm (51.7") -Maximum material thickness: 150mm (5.9") -Positioning speed, X-axis: 80 MPM (262 FPM) -Positioning speed, Y-axis: 80 MPM (262 FPM) -Positioning speed, Z-axis: 20 MPM (66 FPM) -Axis stroke, X-axis: 3752.5mm (14.7") -Axis stroke, Y-axis: 1639mm (64.5") -Axis stroke, Z-axis: 160mm (6.3") BORING UNIT -12 spindles for vertical boring -6 spindles for horizontal boring -Motor: 1.7kW (2.5 HP) -Saw diameter: 120mm (4.7") -Saw unit motor power: 1.7kW (2.5HP) ROUTING UNIT -Motor: 7.5kW (10.5HP) -Connection: ISO30 -Tool shank dimensions: 6-25mm (0.23-1") -10 position ride-along tool magazine -Maximum tool diameter: 160mm (6.3") -Dimensions: 6000 x 2200 x 2100mm (19.7` x 7.2` x 6.9`) -Weight: 3300kg |
| Sales Price: | CALL FOR PRICING |
