| Specification | Date: 9/13/2025 |
| Inventory #: | X5400bh |
| Machine Type: | CNC Routers - Flat Table, Nesting |
| Manufacturer: | Omnitech Selexx/Mate |
| Model: | Omnitech Selexx/Mate |
| Year: | 2006 |
| Region: | Western Canada |
| Voltage: |
//
Can be transformed to required voltage for a nominal fee. Single phase available thru a phase converter. |
| Condition: | Good |
| Machine Capacities: | 2006 Omnitec / Anderson 4 x 8 Machining centre X axis: 1720 mm // 5.643 ft Y axis: 2630 mm // 8.628 ft Z axis: 250 mm // 0.82 ft Table size: 1300 x 2500 mm // 4.265 x 8.202 ft Max feed speeds: X, Y axis: 50 m/min // 164.04 ft/min Z axis: 10 m/min // 32.2 ft/min ATC head: No. 1 of spindles: 1 Tool holder shank: HSK63F, Air cooled Number of tools: 8 Speed: 1.000-24.000 rpm Boring block: No. 2 block (5x5): 4800 rpm Tool diameter: For router bit (O.D): Max 25 mm // 0.984 in. Shank: For boring: 10 mm // 0.394 in. Power: ATC head: 10 hp Boring: 2 hp Vacuum pump: 10 hp Air pressure: 6 kg/cm2 // 85 lb/in.2 Nc controller: Fanuc Alternate voltage: 575 volts Dimensions: Floor area: 4000 x 4400 mm // 13.123 x 14.435 ft Height: 2450 mm // 8.038 ft Weight: 2,450 kg // 5,397 lbs Air consumption: 450 L/min // 15.9 cfm |
| Sales Price: | CALL FOR PRICING |
